Blodgett 6502 Oven Rocker Switch Cook/Cool Down Red DPDT 7/8" X 1-1/2"

SKU: 6502 1-6502 Brand:
Blodgett
Availability:
In Stock
(1)
$27.23 Price reduced from $45.24
Save $18.01
Have a Question? +1 (866) 863-0907

Specifications:

  • [ Red Rocker Switch ] [ Fits Hole 7/8 X 1-1/2 ] [ On/On ] [
  • Dpdt ] [ Terminals 6 (1/4" Tabs) ] [ 15A/125V,10A/250V ]
  • [ Color Red/Chrome Bezel ]
  • [ Markings Man/Auto ] Cool Down
  • Blodgett
  • Oven Series: Bcg, Ctb, Ctbr, Ef/Eze, Fa/Gzl, Re.
  • Zephaire E & G W/Solid State Controls.
  • *For 208V Units*

Description

The Blodgett 6502 Oven Rocker Switch Cook/Cool Down Red DPDT 7/8" X 1-1/2" is a control switch that fits into the compatible commercial ovens to switch between cook and cool-down mode. This is a red, double-pole and double-throw rocker switch that fits into a panel cutout and connects with the control circuitry of the oven. In an actual kitchen application, it enables operators to choose the right mode in the baking process or after cooking. As part of the electrical system of the appliance.

Dimensions:

  • Weight: 0.1 lbs
  • Length: 1.5 in
  • Height: 2.5 in
  • Width: 0.88 in

BLODGETT:

BL6502

Step1: Disconnect power supply before starting to prevent electrical shock.

Step2: Insert switch into mounting cutout and secure.

Step3: Connect wiring to terminals according to circuit diagram carefully.

Step4: Tighten terminals firmly to ensure solid contact and proper connection.

Step5: Restore power and test switch operation under normal load.

  • What maintenance is required for the Blodgett 6502 Rocker Switch?

    Regularly inspect the switch contacts regularly for wear or pitting and ensure secure electrical connections to prevent arcing. Keep the component free from dust and moisture buildup. Use proper voltage ratings to avoid overload and ensure safe operation.

  • What are common issues with the Blodgett 6502 Rocker Switch?

    • Contact wear or arcing under frequent load.
    • Rocker switch sticking or inconsistent actuation.
    • Electrical connection loosening causing intermittent power.
    • Overheating when used beyond rated voltage/current.
    • Internal contact corrosion in humid environments.
