Lincoln LIN369393 Ignition Control Module 24V 60Hz

SKU: LIN369393 1-LIN369393 Brand:
Lincoln
Availability:
In Stock
(0)
$227.50 Price reduced from $482.00
Save $254.50
Have a Question? +1 (866) 863-0907

Specifications:

  • Ignition Control Module Currnet Style
  • 24V, 15 Sec Lockout, 30 Sec P.P., Honeywell,
  • 3-1/2" X 5-1/4"
  • Grey Box Changed To Black Box 6/21/07
  • Special Note: This Is The Ignition Control Module Only
  • To Replace Existing Honeywell Module
  • If Replacing Old Style Johnson
  • Controls Modules G-60 Or G-65 Must Order Oem 369393 Ignition
  • Control Kit And #441417 Transformer
  • For Pilot Burner H1421, M-218, # 51-1380
  • Lincoln Oven 1000 Thru 1005, 1040 Thru 1043, 1050, 1051,
  • 1200, 1201, 1204, 1205, 1240 Thru 1243. 1450,1451,1480

Description

The Lincoln LIN369393 Ignition Control Module 24V 60Hz is the electrical regulating part that initiates the process by controlling the electrical flow to the pilot or main burner assembly. When the thermostat send a signal to the internal circuitry, it produces a high-voltage spark and opens the gas valve to begin combustion. This element is fitted in the electrical section of industrial furnaces to allow pinpoint regulation of the heating cycle. The unit runs on a 24-volt AC circuit at a standard frequency of 60Hz, so that it can be compatible with standard commercial kitchen wiring.

Dimensions:

  • Weight: 1.54 lbs
  • Length: 5.3 in
  • Height: 2 in
  • Width: 4 in

LINCOLN:

369393 4030104

Step1: Disconnect electrical power and shut off the gas supply to the oven before servicing.

Step2: Open the control compartment and locate the existing ignition control module.

Step3: Label and disconnect all wiring connections from the old module.

Step4: Remove the mounting screws and take out the existing control module.

Step5: Install the new ignition control module and secure it in place.

Step6: Reconnect the wiring according to the equipment wiring diagram.

Step7: Restore power and gas, then test the ignition sequence and verify proper burner operation and 15-second lockout functionality.

  • What maintenance is required for the Lincoln LIN369393 Ignition Control Module?

    Inspect electrical connections regularly to ensure tight, corrosion-free terminals. Keep the module clean and dry to prevent moisture damage. Verify proper voltage supply and secure mounting to avoid vibration issues. Routine checks help maintain accurate ignition performance and safe operation.

  • What are common issues with the Lincoln LIN369393 Ignition Control Module?

    • Failure to initiate ignition sequence.
    • Intermittent or weak spark output.
    • Lockout mode engaging unexpectedly.
    • Overheating due to poor ventilation.
