Garland 1758901 Oven Pilot Assembly W/ Igniter & Orifice 24" Wire
Specifications:
- Nat/Lp Pilot, Factory # 5Sl2Er, 1830-734,
- Tube Size 3/16",
- Flame Pattern Right, Igniter W/ 24" Wire
- Lp Orifice # 26-1554
- Nat Orifice # 26-1554
- You Will Need Round Post Ignition Terminal # 85-1063
- If Used For Blue Johnson Control Module G67Ag-3 # 44-1267.
- Garland Oven Model Eco, Ico, Tg
- Us Range Series Cg, Performer Ii, (Left Side Of Standard
- Oven), Performer Ii Convection Oven.
Description
Dimensions:
- Weight: 0.3 lbs
- Length: 3.5 in
- Height: 0.5 in
- Width: 0.88 in
This Part Fits the Following Models
5 modelsStep1: Turn off gas and electrical power; allow oven to cool completely before starting.
Step2: Remove front panel and access old pilot assembly using proper tools.
Step3: Disconnect gas line and igniter wires carefully, label connections.
Step4: Remove old assembly and install new pilot assembly, ensure proper alignment, secure mounting.
Step5: Reconnect gas line and igniter wiring, tighten fittings.
Step6: Restore gas and power, test ignition and flame, check for leaks using leak detector solution.
-
What maintenance is required for the Garland 1758901 Pilot Assembly?
Regularly inspect the igniter and pilot orifice for carbon buildup or blockages and clean carefully. Ensure all gas connections remain tight and leak-free to maintain safe operation. Check wiring for damage or heat damage periodically. Proper maintenance ensures consistent ignition and safe oven performance.
-
What are common issues with the Garland 1758901 Pilot Assembly?
- Pilot fails to ignite due to clogged orifice or debris buildup.
- Weak or inconsistent flame caused by gas flow restriction.
- Igniter malfunction leading to delayed or no ignition.
- Wiring damage causing intermittent electrical connection issues.
