Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module 24V

SKU: G720-BAD-1 1-G720-BAD-1 Brand:
Johnson Controls
Availability:
In Stock
(1)
$180.62 Price reduced from $255.12
Save $74.50
Have a Question? +1 (866) 863-0907

Specifications:

  • 24V Direct Spark Ignition Control Module
  • Johnson # G760Bad-1 ( Discontinued) Now Baso,
  • Baso Black Module Bg1100Maak-1G
  • 0 Pre-Purge, 3 Trials @ 5 Min Intervals, 4 Sec Retry,
  • Includes Rajah Spark Adaptor And Instructions.
  • For Blodget 36432 Use # 44-1596 Control Board.
  • Cleveland Model
  • Skillet Sgl/Sgm-30/40-T/R
  • Garland Model?

Description

The Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module 24V functions to control ignition reliably in improve cooking equipment that uses Blodgett, Cleveland, and Garland models. The module operates efficiently through its zero pre-purge feature while conducting three ignition trials at five-minute intervals with a four-second retry time. Users can install this module through its Rajah spark adaptor while following provided instructions. The BASO BG1100MAAK-1G has replaced the previous ignition module to provide automatic ignition control which improves safety and performance and reduces manual intervention for food service equipment needing dependable ignition control.

Dimensions:

  • Weight: 0.75 lbs
  • Length: 7 in
  • Height: 2.5 in
  • Width: 5 in

CLEVELAND:

2329100 CK4533053 SK2329100

GARLAND:

2329100 4521585 4533053 CK4533053 GL4521585 GLCK4533053

JOHNSON CONTROLS:

720BAD-2 G760BAD-1

Step1: Disconnect all electrical supply and gas flow before starting.

Step2: Remove the old control unit and disconnect each wire connection.

Step3: Install the new module in the same mounting position and secure it tightly.

Step4: Reattach wiring according to the unit’s schematic, ensuring correct polarity.

Step5: Restore power and gas supply, then run a full ignition cycle test.

  • What maintenance is required for the Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module?

    Inspect wiring connections regularly to ensure they are tight and free from corrosion. Keep the module clean, dry, and protected from heat or moisture exposure. Check ignition performance during scheduled system servicing to confirm accurate spark operation and replace if intermittent failures occur.

  • What are common issues with the Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module?

    • No spark output preventing ignition.
    • Intermittent ignition cycling or failure.
    • Burned or damaged relay contacts.
    • Loose or corroded wiring connections.
    • Faulty flame sensing or control signal issues.
    • Overheating leading to shutdown or reset.
