Ice Machine Compressor

Ice Machine Compressor Parts- PartsFeHow to Replace KitchenAid Compressor in an Ice Machine?

Before you replace the kitchen aid ice machine compressor ensure to unplug the ice machine so that there will be no current flow to the machine. Move your appliance away from the wall as we need to open the back part of the appliance.

At the bottom, you will find a way to open the wall. Use the screwdriver to remove the screws and remove the shield, and secure the screws at a corner. You will find the overloaded compressor there. You can use the flat head screwdriver to remove the cover. Disconnect the red-colored wire from the overload.

Also read: Replacement of Evaporator Fan Motor

After doing that, slowly detach the component. Install the new compressor overload. By aligning it to the upper pin connect the wire back to the new one. Realign the component pin if you have removed it earlier. Replace the cover of the compressor overload. Reposition the panel or shield and put it back in the position. Fix the screws accordingly the same way they were removed and do not miss out on any. And your ice machine is ready to use.

Need to find the replacement parts for your ice machine? PartsFe has the replacement parts for all kinds of commercial kitchen equipment.  Here are a few examples of spare parts for ice machine compressors.

Top Selling Products of Compressor:

1) Silver King COMPRESSOR:

The above product is a compressor for the ice machine which is manufactured by SLIVER KING. The product number or OEM part number is 10343-75. The product description is Voltage: 115 V Ac; Includes: Electrical Cover, And Mounting Hardware | Start; Capacitor & Relay, Overload, Filter Dryer; Refrigerant: 404A.  We also have similar models 617468 - Franke,  E617468 - Franke. The dimensions of the products can be Length:11.5in/29.21cm Width:12in/30.48cm Height:11.5in/29.21cm Weight:25.47lbs/11552.99g.

2) True Compressor:

The above product is the compressor in the ice machine manufactured by the TRUE company. The product number or OEM number is 842509. The product is described as 115V/60Hz, R134a. We also have similar models and the product number is E842509 - True. The dimensions of the product are  Length:17.5in/44.45cm and  Width:15in/38.1cm, Height:14.5in/36.83cm Weight:30lbs/13607.76g.

3) Taylor Compressor:

The above product is the compressor spare parts in the ice machine manufactured by TAYLOR. The product number or OEM number is 66795-33. The product description is given as Contactor For Compressor 4-Pole (Old# 12725-33).

We have similar models like 066795-33 - Taylor-Freezer, 12725-33 - Taylor-Freezer.  The dimensions of the product are Length:4in/10.16cmv Width:3.5in/8.89cm Height:2.5in/6.35cm Weight:0.925lbs/419.57g.

4) Baverage Air Compressor:

The above product is the compressor spare part in the ice machine manufactured by Baverage. The product number or OEM number is 302-676B. The product description is given as:  Voltage: 115 V Ac ;Includes: Capacitor, Relay And Overload ;Inlet: 5/16" Odf Suction Line | 1/4" Process Tube / Service;Port ;Outlet: 3/16" Odf Discharge Line ;Refrigerant: R134a.

Similar Models: 8252286 - Franke

We have a wide range of inventory and provide same-day shipping. We only carry the best quality genuine OEM parts in the market from major brands. Browse through PartsFe for more options.
