Genuine OEM Part
main product photo

Parker Hannifin 04E20C1-R3022 Solenoid Valve Assembly 120V

Be the first to review this product
Special Price $65.94 Regular Price $74.50
In stock
SKU
04E20C1-R3022
Add to Wish List
Griddle & Grill Parts, Gas Solenoid Valves, Shop by manufacturers
Manufacturer:
The Parker Hannifin 04E20C1-R3022 Solenoid Valve Assembly is used for regulating the flow of refrigerants like R134A in cooling systems and other industries. It has an input voltage of 120V AC and a frequency of 60 Hz and the power consumption is 9.5 watts. This model is suitable for use with any system that needs fine control of the flow rate. The solenoid valve is designed to offer a smooth operation and fast response and does not leak.

Dimensions

  • Length: 5 In
  • Width: 5 In
  • Height: 3.5 In
  • Weight: 0.55 lbs
https://partsfe.com/media/catalog/product/p/a/parker-hannifin-04e20c1-r3022-solenoid-valve-assembly-120v-41214-2.jpg

Product Notes

  • R134A, 120V/60Hz, 9.5W
PARKER HANNIFIN:
Reviews
Write Your Own Review
You're reviewing:Parker Hannifin 04E20C1-R3022 Solenoid Valve Assembly 120V
Your Rating
FAQS
Customer Questions
What is the Best Electric Griddle?

Electric Griddle is an electronic equipment that uses an electric element as its heat source. It has a large cooking surface often made up of nonstick material. Electric Griddle has a surface which you do not find in the regular stovetop cookware. ...

Read More
What maintenance is required for the Parker Hannifin 04E20C1-R3022 Solenoid Valve Assembly?

Inspect the valve regularly for leaks, corrosion, or debris buildup that may restrict flow. Clean internal components if accessible and ensure proper refrigerant flow. Check coil wiring and connections. Always disconnect power before servicing to prevent electrical hazards and ensure better operation.

What are common issues with the Parker Hannifin 04E20C1-R3022 Solenoid Valve Assembly?

  • Valve not opening or closing properly.
  • Coil failure or no activation.
  • Refrigerant flow restriction or blockage.
  • Internal debris causing sticking.
  • Electrical connection faults.
  • Delayed or inconsistent valve response.

Shipping

We strive to provide our customers with a hassle-free and efficient shopping experience. Our shipping policy ensures the timely delivery of your orders and complete customer satisfaction. View More

Returns

We are committed to ensuring your complete satisfaction with every purchase. We understand that circumstances may arise where you must return a product or request a refund. If for any reason you are not satisfied, you may return the item(s) according to the terms outlined below. View More

Payment Methods

This Payment Policy outlines the terms and conditions governing all payments made for products purchased through our website. By making a purchase, you agree to be bound by this Payment Policy. View More

Installation Steps

Step1: Disconnect electrical power and shut off the refrigerant or fluid supply before starting work.

Step2: Relieve system pressure completely and confirm the line is safe to open.

Step3: Remove the existing solenoid valve by loosening inlet and outlet connections.

Step4: Install the new valve in the correct flow direction and tighten all fittings securely.

Step5: Reconnect coil wiring to the solenoid terminals, ensuring firm and insulated connections.

Step6: Restore system power and fluid supply, then test valve actuation and check for leaks under operation.
