main product photo

Johnson Controls 720BAD-2 Direct Spark Ignition Control Module 24V

Be the first to review this product
Special Price $180.62 Regular Price $255.12
In stock
SKU
720BAD-2
Add to Wish List
Oven Parts, Ignitors, Shop by manufacturers
Manufacturer:
The Johnson Controls 720BAD-2 Direct Spark Ignition Control Module serves as a 24V ignition module that enables dependable spark ignition in improve cooking equipment. The 720BAD-2 Direct Spark Ignition Control Module functions with Blodgett 36432 and Cleveland Skillet SGL/SGM-30/40-T/R and other models. The partfunctions without pre-purge while providing three ignition attempts spaced by five-minute intervals during a four-second retry period. The product bundle contains both the Rajah spark adaptor and step-by-step installation guidelines. This partprovides professional kitchens with reliable ignition functions and user-Interfaceoperation and superior performance benefits.

Dimensions

  • Length: 7 In
  • Width: 5 In
  • Height: 2.5 In
  • Weight: 0.75 lbs
https://partsfe.com/media/catalog/product/j/o/johnson-controls-720bad-2-direct-spark-ignition-control-module-24v-33453-2.jpg

Product Notes

  • 24V Direct Spark Ignition Control Module
  • Johnson # G760Bad-1 ( Discontinued) Now Baso,
  • Baso Black Module Bg1100Maak-1G
  • 0 Pre-Purge, 3 Trials @ 5 Min Intervals, 4 Sec Retry,
  • Includes Rajah Spark Adaptor And Instructions.
  • For Blodget 36432 Use # 44-1596 Control Board.
  • Cleveland Model
  • Skillet Sgl/Sgm-30/40-T/R
  • Garland Model?
JOHNSON CONTROLS:
Reviews
Write Your Own Review
You're reviewing:Johnson Controls 720BAD-2 Direct Spark Ignition Control Module 24V
Your Rating
FAQS
Customer Questions
What maintenance is required for the Johnson Controls 720BAD-2 Direct Spark Ignition Control Module?

The module should be inspected regularly for secure mounting and clean electrical connections to ensure accurate ignition performance. Check wiring terminals for corrosion, looseness, or heat damage. Keep the control area free of dust and moisture. Proper inspection assists maintain better spark ignition and consistent burner operation.

What are common issues with the Johnson Controls 720BAD-2 Direct Spark Ignition Control Module?

  • No spark or intermittent ignition failure.
  • Ignition lockout due to failed flame sensing.
  • Relay or internal circuit failure causing no output.
  • Corroded or loose terminal connections.
  • Repeated reset cycles or failure to complete ignition sequence.
  • Voltage supply issues affecting module operation.

Shipping

We strive to provide our customers with a hassle-free and efficient shopping experience. Our shipping policy ensures the timely delivery of your orders and complete customer satisfaction. View More

Returns

We are committed to ensuring your complete satisfaction with every purchase. We understand that circumstances may arise where you must return a product or request a refund. If for any reason you are not satisfied, you may return the item(s) according to the terms outlined below. View More

Payment Methods

This Payment Policy outlines the terms and conditions governing all payments made for products purchased through our website. By making a purchase, you agree to be bound by this Payment Policy. View More

Installation Steps

Step1: Shut off power and gas supply, then confirm system is fully de-energized.

Step2: Note existing wiring layout before removing the old ignition control.

Step3: Secure the new ignition control module onto the control panel mounting points.

Step4: Transfer each wire to matching terminals as per wiring diagram.

Step5: Restore power and initiate startup sequence while observing ignition action.

Step6: Check better flame detection and shutoff response under normal operation.
