main product photo

Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module 24V

Rating:
5 5 1
1  Review Add Your Review
Special Price $180.62 Regular Price $255.12
In stock
SKU
G720-BAD-1
Add to Wish List
Oven Parts, Ignitors, Shop by manufacturers
Manufacturer:
The Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module 24V functions to control ignition reliably in improve cooking equipment that uses Blodgett, Cleveland, and Garland models. The module operates efficiently through its zero pre-purge feature while conducting three ignition trials at five-minute intervals with a four-second retry time. Users can install this module through its Rajah spark adaptor while following provided instructions. The BASO BG1100MAAK-1G has replaced the previous ignition module to provide automatic ignition control which improves safety and performance and reduces manual intervention for food service equipment needing dependable ignition control.

Dimensions

  • Length: 7 In
  • Width: 5 In
  • Height: 2.5 In
  • Weight: 0.75 lbs
https://partsfe.com/media/catalog/product/j/o/johnson-controls-g720-bad-1-direct-spark-ignition-control-module-24v-63377-2.jpg

Product Notes

  • 24V Direct Spark Ignition Control Module
  • Johnson # G760Bad-1 ( Discontinued) Now Baso,
  • Baso Black Module Bg1100Maak-1G
  • 0 Pre-Purge, 3 Trials @ 5 Min Intervals, 4 Sec Retry,
  • Includes Rajah Spark Adaptor And Instructions.
  • For Blodget 36432 Use # 44-1596 Control Board.
  • Cleveland Model
  • Skillet Sgl/Sgm-30/40-T/R
  • Garland Model?
JOHNSON CONTROLS:
Reviews 1
Write Your Own Review
You're reviewing:Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module 24V
Your Rating
FAQS
Customer Questions
What maintenance is required for the Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module?

Inspect wiring connections regularly to ensure they are tight and free from corrosion. Keep the module clean, dry, and protected from heat or moisture exposure. Check ignition performance during scheduled system servicing to confirm accurate spark operation and replace if intermittent failures occur.

What are common issues with the Johnson Controls G720-BAD-1 Direct Spark Ignition Control Module?

  • No spark output preventing ignition.
  • Intermittent ignition cycling or failure.
  • Burned or damaged relay contacts.
  • Loose or corroded wiring connections.
  • Faulty flame sensing or control signal issues.
  • Overheating leading to shutdown or reset.

Shipping

We strive to provide our customers with a hassle-free and efficient shopping experience. Our shipping policy ensures the timely delivery of your orders and complete customer satisfaction. View More

Returns

We are committed to ensuring your complete satisfaction with every purchase. We understand that circumstances may arise where you must return a product or request a refund. If for any reason you are not satisfied, you may return the item(s) according to the terms outlined below. View More

Payment Methods

This Payment Policy outlines the terms and conditions governing all payments made for products purchased through our website. By making a purchase, you agree to be bound by this Payment Policy. View More

Installation Steps

Step1: Disconnect all electrical supply and gas flow before starting.

Step2: Remove the old control unit and disconnect each wire connection.

Step3: Install the new module in the same mounting position and secure it tightly.

Step4: Reattach wiring according to the unit’s schematic, ensuring correct polarity.

Step5: Restore power and gas supply, then run a full ignition cycle test.
