main product photo

Johnson Controls G777MHA-1 NAT/LP Gas Ignition Control Box 24V

Be the first to review this product
Special Price $152.40 Regular Price $322.88
In stock
SKU
G777MHA-1
Add to Wish List
Ice Machine Parts, Ice Probes & Sensors, Shop by manufacturers
Manufacturer:
The Johnson Controls G777MHA-1 NAT/LP Gas Ignition Control Box 24V functions as a control system for heating applications that use gas ignition systems. The partfunctions at 24V to provide safe ignition operations through its control of gas flow and ignition timing functions. The BASO BG1600M20EP-1AD black box now serves as the replacement model for the original G777MHA-1 NAT/LP Gas Ignition Control Box 24V. The G777MHA-1 provides perfect operation for which use natural or LP gas through its efficient ignition sequence and safety features that deliver reliable performance while minimizing system downtime. This operates frequently in furnaces alongside other gas-fired heating equipment.

Dimensions

  • Length: 7 In
  • Width: 5 In
  • Height: 3 In
  • Weight: 0.8 lbs
https://partsfe.com/media/catalog/product/j/o/johnson-controls-g777mha-1-nat-lp-gas-ignition-control-box-24v-53510-2.jpg

Product Notes

  • No Longer Johnson Control,
  • 1 Trial 50 Sec No Retry, 24V, Johnson, 3 X 4-3/4 Blue Box
  • Replaced With Black Box, Baso Bg1600M20Ep-1Ad
JOHNSON CONTROLS:
Reviews
Write Your Own Review
You're reviewing:Johnson Controls G777MHA-1 NAT/LP Gas Ignition Control Box 24V
Your Rating
FAQS
Customer Questions
What are the Components of an Ice Machine?

An ice machine is a device that produces and stores ice. It is used by people who wish to have cold drinks or food at home, or by those who wish to have cold storage for their Refrigerators Parts. ParstFe is your one stop solution for Manitowoc, Scotsman...

Read More
What maintenance is required for the Johnson Controls G777MHA-1 Ignition Control Box?

Keep ignition control box dry and free from dust. Inspect wiring connections regularly for corrosion or looseness. Ensure proper voltage supply and secure mounting to prevent vibration damage during operation.

What are common issues with the Johnson Controls G777MHA-1 Ignition Control Box?

  • Failure to ignite gas due to control board malfunction or power interruption.
  • Intermittent ignition cycles caused by wiring faults or loose terminal connections.
  • No spark output or inconsistent flame sensing leading to burner shutdown.

Shipping

We strive to provide our customers with a hassle-free and efficient shopping experience. Our shipping policy ensures the timely delivery of your orders and complete customer satisfaction. View More

Returns

We are committed to ensuring your complete satisfaction with every purchase. We understand that circumstances may arise where you must return a product or request a refund. If for any reason you are not satisfied, you may return the item(s) according to the terms outlined below. View More

Payment Methods

This Payment Policy outlines the terms and conditions governing all payments made for products purchased through our website. By making a purchase, you agree to be bound by this Payment Policy. View More

Installation Steps

Step1: Turn off gas supply and disconnect electrical power completely.

Step2: Open control panel and place existing ignition module.

Step3: Label and disconnect all wiring connections.

Step4: Remove mounting screws and take out old control box.

Step5: Install new ignition control box in same position and secure firmly.

Step6: Reconnect wires according to wiring diagram and terminals.

Step7: Restore power and gas, then test ignition cycle safely.
