How to Replace Water Inlet Valve in Ice Machine?

If your ice machine is not filling the water to the level you needed then the water inlet valve should be replaced. The water inlet valve controls the flow of water in the ice maker. You might need 20 minutes of your time to complete this process if you are replacing a water inlet valve.

The tools that are required to perform this activity are a nut driver set, wrench set, work gloves. Before starting the process ensure to wear work gloves to protect your hands so that they will not be affected in any worst situation.

Unplug the power cord from the wall outlet. Close the water supplies. Now slowly disconnect the refrigerator water supply line. Also, place a towel underneath it. Water can be leaked when disconnecting the water valves. After disconnecting the water supply line, close the water supply cutoff valve. Now loose the below nut and remove the screws and remove the panel or the shield at the bottom of the ice machine. Also, lose the compression nut.

Also Know About: Fridge Timer Replacement

Remove the screws which are mounted in the bracket space and gently remove the water inlet valve. After pulling it out you will see a connection of two wires, called a harness. Detach the wire harness. Now disconnect the water supply line, which is in the fitting collar supply line, and pull the water line out. Replace the new water inlet valve.

Now push the ice maker water supply line into the valve outlet fitting. Position as the same you have removed it. Fix it with the mountain screws. Put back the compartment bracket in position or cover and fix it back with the screws. Now connect the waterline using the screwdriver. Turn on the water cut-off supply valve. Reconnect it back to the refrigerator water supply line. Turn on the power and check the flow of water.

Here are four example products from our website PartsFe to make your search easier.

We provide all kinds of spare parts for your commercial kitchen. Water Inlet valves are one of the spare parts that we provide to many of our customers. We have a wide range of inventory where you can dive in and choose the best one that suits your equipment.

1)Water Inlet Valve for 630900786 Cornelius - Part# 630900786:

The above product is the water inlet valve manufactured by Cornelius. The product number or the OEM number is 630900786. The product is described as Water Inlet Valve, 120V, 3 Gpm; Cornelius Ice Cuber 322, 330, 522, 530. We have similar models like 1012545 - Cornelius. The dimensions of this product are Length:3.5in/8.89cm and width would be  2.125in/5.4cm. The height can be around  3.5in/8.89cm and the weight is approx  0.55lbs/249.48g.  Check out our website for more similar products. Ensuring you the same day delivery with us. No worries keep checking out more products.

2) WATER INLET VALVE - 240V for Manitowoc - Part# 000009126:

The above product is a water inlet valve manufactured by one of the best ones in the town named Manitowoc. The product number or the OEM number is 000009126. The product is described as Water Inlet Valve, 240V, .50 Gpm, 10W, 50/60Hz;Manitowoc Id0302a, Id0303w, Id0523w, Id1072c, Id1472c,;Iy0304a, Iy0305w, Iy0524a, Iy0525w, Iy1074c, Iy1474c,;Sd0302a, Sd0303w, Sd0322a, Sd0323w, Sd1472c, Sr0300a,;Sr0301w, Sr0320a, Sr0321w, Sy0304a, Sy0305w, Sy0324a,;Sy0325w, Sy1474c. We have similar models as the product like 00000376 - Manitowoc, 9126 - Manitowoc. The dimensions of the product are Length:4.5in/11.43cm Width:3.5in/8.89cm Height:3in/7.62cm Weight:0.5lbs/226.8g. The best price for any product is given. We choose the best products in the town at the best price. So that it can be affordable for everyone.

3) WATER INLET VALVE - 120V for Cecilware - Part# CD257:

The above product is a water inlet valve manufactured by Cecilware. The product number or the OEM number is CD257. The product is described as Water Inlet Solenid Valve, 120V; Cecilware Bc1, Bc120, Bc2, Bc2-It, Bc240, Bc301, Bc301-It,; Bc302, Bc302-It, C-2003G-It, C-2003Lg-It, C-2003Rg-It, Gb1cp, Gb1hc-Cp, Gb2cp, Gb2hc-Cp, Gb3cp, Gbk, Gblp, Gbm5.5,; Gbski, Java 2-Qb-D, Java 2-Qb-D1, Java 2-Qb-D2, Java;2-Qb-D3, Java 2-Qb-Dc, Java2-Lp. We have similar models in the same brand like CD257L - Cecilware, CD257L - Grindmaster. The dimensions of this product are Length:3.25in/8.26cm Width:2.25in/5.72cm Height:3in/7.62cm

Weight:0.2lbs/90.72g. We have the best customer service to provide you at any time you open the website. Irrespective of any time our team is always ready to assist you with all your queries.

4)  WATER INLET SOLENOID for Scotsman - Part# 12-2922-01:

The above product is a water inlet valve manufactured by Scotsman. The product number or OEM number is 12-2922-01. The product is described as Water Inlet Solenoid Valve;120V, 60Hz, 10W ;Dole Valve;Scotsman C0322, C0330, C0522, C0530, C0630, C0830, C1030,;Eh222. We have similar models in the same brand as 12292201 - Scotsman, SC12-2922-01 - Scotsman, SC12-3124-01 - Scotsman. The dimensions of the product are Length:4in/10.16cm Width:4in/10.16cm Height:2in/5.08cm Weight:1.2lbs/544.31g.

Check out our website for more exciting and suitable products. All the spare parts for your kitchen in one place, at PartsFe.
