Turbo Air 30283L0100 Refrigerator Thermostat W/different Cool Settings 40.1F IN 24.8F OUT

Rating:

8 Reviews Add Your Review

Special Price $132.40 Regular Price $204.00

In stock

SKU

30283L0100

Categories: Electrical & Hardware, Thermostats,

Manufacturer:

Turbo Air

The Turbo Air 30283L0100 Thermostat delivers exact temperature management through its multiple cooling options which optimize system performance. The thermostat functions in improve refrigeration by allowing users to select between three adjustable temperature settings which include normal mode at 40.1°F in with 24.8°F out and cold mode at 40.1°F in with 21.2°F out and extra cold mode at 40.1°F in with 17.6°F out. The adjustable temperature settings of this partenable efficient food preservation by maintaining the desired temperature. The partoffers reliable user-Interfaceoperation because it integrates seamlessly with Master-Bilt and Turbo Air systems during installation.

Dimensions

Weight: 0.25 lbs

Details

Regulating temperature within commercial freezer equipment, the Turbo Air 30283L0100 Freezer Thermostat With Different Cool Settings 40.1°F IN 24.8°F OUT is a temperature-control component used to manage the refrigeration cycle according to the sensed cabinet condition. The thermostat responds to temperature changes and controls the connected cooling circuit as the freezer reaches or moves away from its designated operating condition. Its function connects temperature sensing with refrigeration-cycle control.

Temperature Sensing:
Regulates freezer operation by cycling the refrigeration system according to the selected cooling setting. It responds to changes in cabinet temperature and controls compressor operation to help maintain consistent storage temperatures throughout normal operating cycles.

Cooling Control:
Functions as part of the refrigeration control system by monitoring cabinet temperature and regulating the compressor operating cycle. When the sensed temperature reaches the thermostat's switching point, it changes the electrical circuit to start or stop compressor operation as required. This control action helps maintain the selected cooling conditions by coordinating compressor operation with changing cabinet temperatures throughout the refrigeration cycle.

Replacement Guidelines:
Replace the Turbo Air freezer thermostat if it is damaged, responds inconsistently, or no longer provides reliable temperature control. The part number 30283L0100 should be verified before replacement to ensure the correct thermostat is selected. Replace the component if deterioration affects temperature sensing, control response, temperature regulation, or normal freezer operation.

Common Failure Symptoms:

Inconsistent freezer cabinet temperature.
Compressor runs continuously.
Compressor does not cycle during normal operation.
Difficulty maintaining the selected cooling setting.
Irregular refrigeration cycling.

Equipment Compatibility:
The Turbo Air 30283L0100 Freezer Thermostat is used with compatible commercial freezers requiring this thermostat configuration. Verify the equipment model number, part number, and manufacturer documentation before purchase to confirm the correct application.

Technical Specifications:
Product Type: Thermostat with Cool Settings
Part Number: 30283L0100
Brand: Turbo Air
Appliance Type: Commercial Freezer
Temperature Reference: 40.1°F IN / 24.8°F OUT

Replaces Parts

MASTERBILT:

02-70901, 02-71621, 02-72652, MB02-70901, MB02-72652

RANCO:

K55-Q5607

TURBO AIR:

30283L0100, R7232-030, TRBA30283L0100

Reviews 8

Write Your Own Review

FAQS

Customer Questions

Can this thermostat operate efficiently in environments with high ambient temperatures, such as kitchens with cooking equipment generating heat?

Refrigerator thermostats are designed to operate in varying ambient temperatures. Refer to the product specifications or contact the manufacturer to ensure compatibility with high-temperature environments.

How does this thermostat handle power outages, and does it have any features to prevent temperature fluctuations during such events?

Some thermostats feature power outage recovery mechanisms to minimize temperature fluctuations. Check the product specifications or inquire with the manufacturer for details on power outage handling.

Can this thermostat accommodate multiple refrigeration units in a kitchen setup?

Thermostats support multiple units and may offer centralized control options. Check the product documentation or contact the manufacturer to confirm compatibility with your specific setup.

What maintenance is required for the Turbo Air 30283L0100 Thermostat?

Regularly inspect the thermostat for dust, debris, or corrosion on terminals to ensure accurate temperature control. Clean gently with a dry cloth and avoid moisture near electrical parts. Check calibration periodically and adjust as needed to maintain consistent cooling and prevent food spoilage. Always disconnect power before servicing for safety.

What are common issues with the Turbo Air 30283L0100 Thermostat?

Inconsistent temperature regulation causes food to freeze or spoil.
Refrigerator not cooling due to thermostat failure.
Compressor not cycling on or off properly.
Thermostat contacts are sticking or failing to respond to temperature changes.
Intermittent cooling performance or sudden shutdowns.

What is the Turbo Air 30283L0100 Freezer Thermostat used for?

The Turbo Air 30283L0100 is used to provide temperature-based control within compatible commercial freezer equipment.
