How to Replace Manitowoc Ice Machine Control Board

Do you need to replace the Manitowoc Ice Machine control board in your ice machine ice maker? Control Board is an important part of the ice machine that controls many functions including the turning on and off of the unit and dispensing ice. It's easy to replace this board but before you do, take a look at what kind of warranty your ice machine has. Whether you need a Manitowoc or another manufacturer's replacement part, PartsFe is your one-stop shop for everything you need.

If you're ready to replace your Manitowoc Ice machine parts, these six steps will help make this process a breeze. Keep reading and learn how to replace one of the boards with ease!

It's critical to set up a Manitowoc ice maker's replacement control board properly.

Know more about trouble shooting Fridge Timer

Manitowoc Control Board available at PartsFe

1) Manitowoc Control Board 8309

Manufacturer Name: Manitowoc

Product Number: 000008309

OEM Part Number: 000008309

Product Description: The Manitowoc Ice 000008309 Control Board manages all operational tasks and records data history. These real OEM control boards are compatible with and work with your particular ice maker. Also, these control boards fit models I0600, I0870C, I1106, and more variants.

2) Manitowoc Ice 2006199 control board:

Manufacturer Name: Manitowoc

Product Number: 2006199

OEM Part Number: 2006199

Product Description: Manitowoc Ice 2006199 control board is a component that provides the essential functions for the ice machine to operate. The control board receives signals from the cold control sensor and converts these signals into ice making cycles. It also monitors and sequences the defrost cycle.

2) Manitowoc Control Board 7627823

Manufacturer Name: Manitowoc

Product Number: 7627823

OEM Part Number: 7627823

Product Description: The Manitowoc 7627823 control board is best suited for J, Q, and Ib models of the company's ice machine series.

Follow the procedures listed below to replace the new control board manually or through USB and to set it up.

USB Set-Up for Control Board Replacement

You can use the USB setup instructions if the control boards are still functional but intermittently having problems, or if they are functional but mechanically damaged. In order to export the data for transfer to the new control board, you will want a flash drive to perform this. The previous control board must be disconnected from the ice maker unit while data transfer is ongoing.

Make sure that the flash drive you're using doesn't have any built-in software before continuing with the USB setup. For more information, see the USB Flash Drive Specifications and Formatting.

Step 1: Verify the ice maker's power source once more.

Step 2: Select the Menu option.

Step 3: Highlight "Service" by pressing the Down arrow button.

Step 4: Click the checkbox to choose the "Service" menu.

Step 5: Once more using the Down arrow, scroll down until you find and highlight "USB Setup."

Step 6: Click the Checkmark button once again to choose "USB Setup," after which "USB Stick" will be highlighted.

Step 7: To access a menu for USB exporting, press the Checkmark button a

second time.

NOTE: The choices "Export All" and "Export Setup" for exporting data are available to you. Four files—"Asset Data," "Operating Data," "Real Time Data," and "Settings"—will be sent to the flash drive when you click "Export All." If you're configuring numerous units the same way, you can choose "Export Setup," which will just export the "Settings" file onto the flash drive.

Step 8: Choose "Export All" and click the Checkmark button to confirm your choice. A display with instructions will then emerge as a result.

Step 9: Comply with the "Export All" instructions as stated below.

• Insert the USB stick into the control board's USB port.
• By clicking the Checkmark button, you can confirm.
• For the download to complete transferring, wait for the computer for 5–10 minutes.
• Export Successful / Completed—Download transmission is complete.

Step 10: At this point, the ice maker's control board can be changed and the power can be turned off.

Know more about Replacement Water Inlet Valve

USB Set-Up After Replacing Control Board

The new control board needs to be set up after it has been installed. The options for "Manual Setup" and "USB Setup" should appear on the screen after power is restored. You must now follow the setup instructions in the "Replacement Control Board" setting under "Service Menu" if the new control board was preprogrammed with an earlier firmware version. These are the actions:

Step 1: Select the Menu option.

Step 2: Scroll to "Service" using the Down arrow button. When selected, it will be highlighted.

Step 3: In step 3, choose "Service" by checking the box. The "Service" menu will then appear.

Step 4: Using the Down arrow button to navigate the choices, choose "Replacement Control Board".

Step 5: To confirm your choice, press the Checkmark button while selecting "Replacement Control Board." Then, you'll have the choice between "Manual Setup" and "USB Setup." Choose the right setup strategy.

“USB SETUP”-

Step 1: Press the Down arrow button to select the "USB Setup" option and highlight it.

Step 2: Click the Checkmark button to confirm your choice.

Step 3: A screen will show you instructions. They will read as follows:

• First, connect the flash drive to a USB port.
• Press the checkmark icon to confirm.
• Wait for "Manual Setup" and "USB Setup" to finish downloading.
• These choices will show up after the download is finished.

“Manual SETUP”-

Step 1: Highlight "Manual Setup" in the menu to choose it.

Step 2: To confirm your choice, click the Checkmark button.

Step 3: Verify that the automatically filled date is accurate.

Step 4: Press the Right arrow button after selecting the date to activate a blinking cursor on the left-hand bracket if the date is incorrect.

Step 5: After entering the right date using the Up and Down arrows, press the Right arrow button to make the blinking cursor stop.

Step 6: Press the Down arrow button to move the bracket below "Input Model#" if the date is right.

Step 7: Click the Right arrow button to make the left-hand bracket's cursor blink.

Step 8: To make the letter "A" appear, use the Up arrow button. In order to reach the initial letter of the Model Number, "I," keep pressing the Up arrow.

Step 9: To move the pointer right, press the right arrow button. Press the Right arrow button after scrolling up and down until you find the next letter in the model number. Continue until you have entered the model number entirely. Incorrect model number entry will result in an error message. Put the model number in again.

IMPORTANT: Ensure that the voltage nomenclature is entered after the model number.

Step 10: Press the Right arrow button until the cursor is no longer visible on the screen.

Step 11: Repeat Steps 7–10 until the brackets are next to "Input Serial#" on the screen.

Step 12: Use the Checkmark button to pick [Exit >] after swiping down the menu to get there.

Step 13: The screen will switch back to the [Manual Setup>] screen after a brief wait.

Step 14: Disconnect the power to the control board, then re-connect it so that the board may reboot with the newly-inputted model and serial number.

Know more about trouble shooting of Refrigerators Air Filter

Manual Set-Up for Control Board Replacement from Set-Up Menu

Step 1: On the Main Menu, scroll down with the Down arrow button until "Setup" appears. Use the Checkmark button to choose.

Step 2: Adjust the machine's settings as necessary. Refer to the chart of factory settings below if necessary.

Step 3: To return to the Main Menu after completing this step, hit the Left arrow button.

Here’s Manitowoc Ice Machine Control Board Factory Default Settings:

Manitowoc Ice Machine Setting	Default
Language to select	English
Time and Date Setting	USA Central Time
Time configurations	Month/Day/Year/ 24-hour
Units	Fahrenheit/Lbs/Gallons
Clarity of Ice	Off
LCD brightness	Level 2
Password to on	You can off or else use default password 1234 to on
Edit password	off
Clean reminder	off

AuCS runtime	off
Air filter	off
Water Filter	off
LUMINICE	No
Ice bin sensor	None



Whether you're a restaurant owner, or a tech professional, or a business who provides repair services, you should know that replacing your machine's control board is a vital part of any home appliance repair. In this article, we have discussed how the Manitowoc Ice machines Control Board can be replaced.

We have also provided a few suggestions for replacing the control board. PartsFe is the right place for your Manitowoc Ice Machine Parts needs. We have a broad selection of Control Boards in stock, so keep checking back!
