Pitco PTP5045642 Gas Valve 1/2"
Special Price $257.32 Regular Price $513.00
In stock
SKU
PTP5045642
Manufacturer:
The Pitco PTP5045642 Gas Valve is a flow control system with a 1/2" connection designed to be integrated into commercial cooking equipment. It works by regulating the amount of gas supplied to burners according to the system requirements, allowing the regulation of the temperature accurately. It is installed in the gas line of the appliance it is used together with ignition operation. In actual kitchen settings this valve aids in maintaining the heating efficiency of appliance start-up. Its contribution to the system, is vital as it directly influences fuel control, burner and overall secure functioning of the equipment.
Dimensions
- Length: 4.5 In
- Width: 2.5 In
- Height: 2.5 In
- Weight: 2.1 lbs
Product Notes
- [ Nat Gas ] [ Size 3/4" Fpt ] [ Nat Safety ][ 3.5"Wc ]
- [Bleed Gas Actuator] [ Width 4"] [ Brand Rsw ]
- 1/4" Cct Pilot Out Only, W/Slotted Thermopile Magnet
- 3/4" X 1/2" Reducer Bushings, Model 7000 Bmsgor
- Bleed Gas Ports 1/4" Cct, 300,000 Btu
- **Use # 51-1470 To Convert To Lp Gas.**
- Thermopile, H231, T-103, # 51-1122, Screw In Type, 3/8-32
- Brass Pile Holding Nut, 3/8-38 Thread For Magnet, 750Mv,
- 500Mv Under Load.
- Southbend Fryer Series: 14,18.
- Vulcan Hart Fryer 7891G, 7892G, Hf91G, Hf92G.
- Wolf Fryer Ss-Wtf-42, Wtf-42.
