Southbend 9-3174-1 Gas Broiler Relay DPDT 120V
Special Price $301.37 Regular Price $346.40
In stock
SKU
9-3174-1
Manufacturer:
The Southbend 9-3174-1 Gas Broiler Relay manages electrical switching within the heating control circuit. Incoming control voltage energizes the relay coil, causing internal contacts to transfer between designated terminals and redirecting connected circuits. The DPDT arrangement provides two poles, with each pole switching between two contact positions, allowing separate electrical paths to change state through a single relay. The 120V rating identifies the coil voltage required for energization. The contact transfer subsequently coordinates signals with the associated controls during the broiler heating procedure.
Dimensions
- Length: 2 In
- Width: 1.95 In
- Height: 1.4 In
- Weight: 0.5 lbs
