Legion 431138 Direct Spark Ignition Module W/ 11 Sec Lockout, 5EA 1/4" Tab Terminals
Special Price $212.85 Regular Price $340.88
In stock
SKU
431138
The Legion 431138 Ignition Module operates by producing a high-voltage spark to start the gas in the burner system to maintain a steady flame start-up during the operation. It takes electrical inputs of the control system and transforms them into the energy needed to initiate combustion efficiently. The module is fitted in the burner assembly, or control compartment of a commercial kitchen appliance, such as an oven, range or fryer, where it is directly connected to the ignition electrodes and wiring harness.
Manufacturer:
Dimensions
- Length: 5.125 In
- Width: 4 In
- Height: 2 In
- Weight: 1.2 lbs
Product Notes
- 25V Direct Spark Ignition Module,
- 11 Sec Lockout, 5Ea 1/4" Tab Terminals, 3 Amp Fuse (Ap#
- 381050),
- Rajah Spark Term & 1/4" Spark Term On Top.
- 4" X 5-1/16"
- For Use With A Flame Sensor And Ignitor.
- Before 1998 Use Spark Cable 27", # 38-1334
- 1998 And After Use 20" Spark Cable, # 38-1363
- Frymaster
- Fryer Fh250, G18Fb, G24Fb, Gl18Fb,
- Gl24Fb, He, Mach52, Mjh50.
