Hobart 00-417980-00001 Fryer Ignition Control Module 24V F429 CA-145
Special Price $197.79 Regular Price $387.03
In stock
SKU
00-417980-00001
Manufacturer:
The Hobart 00-417980-00001 Ignition Control Module 24V F429 CA-145 controls the refueling sequence and tracks the operation of the burner in a commercial fryer. It is connected to the fryer's control circuit and will start the ignition and assist in controlling the burner cycle under operating conditions. This module is mounted within the electrical control compartment of the fryer and works with the ignition and gas control parts. It has been widely used in commercial foodservice equipment and is an essential part of the ignition process that is necessary for heating cooking oil in a fryer.
Dimensions
- Length: 5.5 In
- Width: 4 In
- Height: 2 In
- Weight: 0.75 lbs
Product Notes
- Ignition Control Module 24V, F429, Ca-145, # 441283
- S8600H3002,
- 1 Mv, 2 Mv/Pv, 3 Pv,
- 4 Gnd(Burner), 5 24V(Gnd), 6 24V, 9 Spark, 90 Sec
- New/Style Black Box W/ Spark Connection On Top
- Groen Kettle, Marshall Air Broiler.
- For Vulcan Hart:
- Nat/Lp Pilot, H501, # 51-1467
- Ignition Cable, Vul419359 (Non-Stock)
- Vulcan Model 1Gr45M, 1Gr65M, 1Gr85M, 1Grc35, 1Grc45,
- 1Grc65,1Grd45, 1Grd65, 1Grs35, 1Grs45, 1Grs65, Ef3, Ef4,
- Ef5, G40Tb, Gr35,Gr35F, Gr45, Gr45F, Gr65, Gr65F, Gr85,
- Gr85F, Grc35F,Grc45F, Grc65F, Grc85F, Grd35F, Grd45F,
- Grd65F, Grd85F,Grs35F, Grs45F, Grs65F, Grs85F
