Marshall Air 501614 Fryer Ignition Control Module 24V F429 CA-154
Special Price $197.79 Regular Price $387.03
In stock
SKU
501614
Manufacturer:
The Marshall Air 501614 Ignition Control Module F429 CA-154 manages the startup of a burner system based on operational signals and regulates the refueling sequence in a fryer system. It tracks the development of ignition events and can manage the electrical control of connected heating elements. This is a 24V module installed in the control housing of the fryer, in combination with the ignition and gas control assemblies. The module controls the operation of the heating system in the fryer during kitchen production, enabling it to maintain a controlled operation of the fryer during cooking.
Dimensions
- Length: 5.5 In
- Width: 4 In
- Height: 2 In
- Weight: 0.75 lbs
Product Notes
- Ignition Control Module 24V, F429, Ca-145, # 441283
- S8600H3002,
- 1 Mv, 2 Mv/Pv, 3 Pv,
- 4 Gnd(Burner), 5 24V(Gnd), 6 24V, 9 Spark, 90 Sec
- New/Style Black Box W/ Spark Connection On Top
- Groen Kettle, Marshall Air Broiler.
- For Vulcan Hart:
- Nat/Lp Pilot, H501, # 51-1467
- Ignition Cable, Vul419359 (Non-Stock)
- Vulcan Model 1Gr45M, 1Gr65M, 1Gr85M, 1Grc35, 1Grc45,
- 1Grc65,1Grd45, 1Grd65, 1Grs35, 1Grs45, 1Grs65, Ef3, Ef4,
- Ef5, G40Tb, Gr35,Gr35F, Gr45, Gr45F, Gr65, Gr65F, Gr85,
- Gr85F, Grc35F,Grc45F, Grc65F, Grc85F, Grd35F, Grd45F,
- Grd65F, Grd85F,Grs35F, Grs45F, Grs65F, Grs85F
