Hobart 857207-1 Fryer Ignition Control Module 24V F429 CA-158
Special Price $197.79 Regular Price $387.03
In stock
SKU
857207-1
Manufacturer:
The Hobart 857207-1 Fryer Ignition Control Module F429 CA-158 regulates the ignition sequence and timing of the electrical signals needed to start up the burners. It is compatible with the appliance parts and controls the ignition timing, flame sensing operations, and control responses during operation. It is a 24-volt control module that is mounted inside the electrical compartment of commercial fryers and works in combination with the ignition system. The module acts as a central control unit and interfaces with burners, sensors, and connected circuits.
Dimensions
- Length: 5.5 In
- Width: 4 In
- Height: 2 In
- Weight: 0.75 lbs
Product Notes
- Ignition Control Module 24V, F429, Ca-145, # 441283
- S8600H3002,
- 1 Mv, 2 Mv/Pv, 3 Pv,
- 4 Gnd(Burner), 5 24V(Gnd), 6 24V, 9 Spark, 90 Sec
- New/Style Black Box W/ Spark Connection On Top
- Groen Kettle, Marshall Air Broiler.
- For Vulcan Hart:
- Nat/Lp Pilot, H501, # 51-1467
- Ignition Cable, Vul419359 (Non-Stock)
- Vulcan Model 1Gr45M, 1Gr65M, 1Gr85M, 1Grc35, 1Grc45,
- 1Grc65,1Grd45, 1Grd65, 1Grs35, 1Grs45, 1Grs65, Ef3, Ef4,
- Ef5, G40Tb, Gr35,Gr35F, Gr45, Gr45F, Gr65, Gr65F, Gr85,
- Gr85F, Grc35F,Grc45F, Grc65F, Grc85F, Grd35F, Grd45F,
- Grd65F, Grd85F,Grs35F, Grs45F, Grs65F, Grs85F
